Rion รุ่นNL-62Aเดรื่องวัดระดับเสียง,Low Frequency Precision Sound Level Meter NL-62A Type Approval No. TF164

Rion รุ่นNL-62Aเดรื่องวัดระดับเสียง,Low Frequency Precision Sound Level Meter NL-62A Type Approval No. TF164
รหัสสินค้า SKU-06884
หมวดหมู่ เครื่องมือวัดด้านสิ่งแวดล้อม(Environmental Measuring Instrument)
ราคาปกติ 250,000.00 บาท
ลดเหลือ 0.00 บาท
สถานะสินค้า Pre-Order
ลงสินค้า 31 พ.ค. 2564
อัพเดทล่าสุด 20 ธ.ค. 2565
คงเหลือ 1 ชิ้น
จำนวน
ชิ้น
หยิบลงตะกร้า
หนังสือรับรองบริษัท
บุ๊คแบ๊งค์
คุ้มครองโดย LnwPay
Measures a wide band from 1Hz to 20000Hz.
Measurement method precision sound level meter suitable for all situations from low frequency sound to noise.
● Measurement frequency range 1Hz to 20000Hz
● Easy operation without manual
● Waterproof IP54
● Continuous measurement for 1 month
● Large color LCD screen
● Compatible with rechargeable batteries
● Includes function expansion program “NX-42EX”
● Abundant Expanded functions as an option
● Applicable standards: JIS C 1509-1: 2017 Class 1, ISO 7196: 1995, etc.
RION Low Frequency Precision Sound Level Meter NL-62A Type Approval TF164 Specifications

Model NL-62A
Type approval number No. TF164
(designated acoustic calibrator: NC-72A, NC-75)
Conformity standard Measurement Law Precision Sound
Level Meter JIS C 1509-1: 2017 Class 1,
JIS C 1516: 2014 Class 1,
IEC 61672-1: 2013/2002 class 1,
ANSI / ASA S1.4-2014 / Part1 class 1
ISO 7196: 1995
CE marking
Measurement function
* Simultaneous measurement with selected time weighting characteristics and frequency weighting characteristics
Calculation (main channel) Time-weighted sound level  L p
Time-weighted sound level  L eq
Acoustic exposure level  L E
Time-weighted sound level maximum  L max
Time-weighted sound level minimum  L min
Time-rate sound level  N (05, 10, 50) , 90, 95) up to 5
Operation (sub ch) Time-weighted sound level  L p
Additional operations One of the following items selectable
C characteristic time average sound level LCeq
G characteristic time average sound level LGeq
C characteristic peak sound level LCpeak
Z characteristic peak sound level LZpeak
et characteristic time average sound level LA et eq
of d characteristic time average sound level Maximum value LA emax
* Since the frequency characteristics of the additional calculation are
linked to the frequency characteristics of the subchannel
, LA eeq and LA emax can be selected when the subchannel has A characteristics.
For C characteristic, G characteristic, and Z characteristic, additional operations LCeq
and LCpeak, LGeq, and LZpeak can be selected.
Calculation time 10 seconds, 1, 5, 10, 15, 30 minutes, 1, 8, 24 hours and any time can be set manually Autostore: Up to
1000 hours
Microphone Model UC-59L
Sensitivity level -27 dB
Measurement level range A characteristic: 25 dB to 138 dB, C characteristic: 33 dB to 138 dB,
G characteristic: 43 dB to 138 dB, Z characteristic: 50 dB to 138 dB,
C characteristic peak sound level: 60 dB to 141 dB,
Z characteristic Peak sound level: 65 dB to 141 dB
Self-noise level A characteristic 17 dB or less
C characteristic 25 dB or less
G characteristic 35 dB or less
Z characteristic 42 dB or less
Measurement frequency range 1 Hz to 20 kHz
Frequency weighting characteristics A, C, G and Z characteristics
Time weighting characteristics F (fast) and S (slow), E (impulse) and 10 s
Level range switch None (Linearity range 113 dB)

Bar graph display range
Maximum 110 dB (20-130 dB)
Bar graph display switching Set the upper and lower limits of the bar graph in 10 dB increments
Efficacy detection circuit Digital calculation method
Sampling cycle L p , L eq, L E, L max, L min, L peak: 20.8 μs (sampling frequency 48 kHz)
N  : 100 ms (0.1 s)
Correction function
Windscreen correction function Compliant with JIS C 1509-1, JIS C 1516, IEC 61672-1, ANSI / ASA S1.4 even when the windscreen is installed.
Diffuse sound field correction function
Corrects the frequency characteristics of the diffuse sound field so that it conforms to the standard (ANSI / ASA S1.4).
Delay time Set the time from when the start key is pressed until the measurement starts (OFF, 1, 3, 5, 10 seconds)
Last-minute data removal function
(back erase function)
When the measurement is paused with the PAUSE / CONT key, the data that goes back the set time from that point is excluded from the calculation (OFF, 1, 3, 5 seconds).
display Backlit TFT color translucent liquid crystal display WQVGA (400 x 240 dots)
* The liquid crystal display has a touch panel (capacitance type) control
Numerical display update cycle 1 s
Bar graph update cycle 100 ms
Store manual Manually record the measurement results one address at a time

Number of manually recorded data
Internal memory: Up to 1000 data sets
SD card: Depends on the capacity of the SD card * 1
Auto * 2 Automatically continuously records the instantaneous value for each set time ( L p mode) and the calculated value for each set time ( L eq mode)
Auto
L p store cycle
100 ms (0.1s), 200 ms (0.2s), 1 s, L eq 1s
Auto
L eq operation cycle
10 seconds, 1, 5, 10, 15, 30 minutes, 1, 8, 24 hours
Auto
measurement time
Up to 1000 hours (depending on SD card capacity) * 1
Data recall Browse store data
Setting memory Up to 5 sets of settings can be saved in the internal memory and recalled. Can be
started with the settings of the file stored in the SD card in advance.
Waveform recording * 3 file format Uncompressed waveform WAVE file
Sampling frequency Select from 48 kHz, 24 kHz, 12 kHz
Data length Select from 24 bit and 16 bit
output DC output Outputs a DC signal corresponding to the frequency weighting characteristic and time weighting characteristic selected by calculation
DC output voltage Bar graph display 2.5 V, 25 mV / dB at full scale
AC output Interlocked with the frequency weighting characteristic selected by calculation, the AC signal is output with the frequency weighting characteristic selected from A, C, and Z.
AC output voltage Bar graph display 1 Vrms (effective value) at full scale
Comparator output * 2 Turns on when the set level is exceeded at the open collector output (maximum applied voltage 24 V, maximum current 60 mA, allowable loss 300 mW).
USB Can be connected to a computer and recognized as a removable disk Can
be controlled by communication commands
RS-232C communication RS-232C communication is possible by using a dedicated cable
Continuous data output * 2 Data type Instantaneous value L p
Calculated value L eq, L max, L min, L peak
Output interval 100 ms (0.1s)
Power supply 4 AA batteries (alkaline or rechargeable) or external power supply
Operating time (23 ° C) Alkaline battery LR6: 16 hours
Ni-MH secondary battery: 16
hours * Operating time varies depending on the setting
AC adapter NC-98E
External power supply voltage 5 to 7 V (rated voltage 6 V)
Current consumption 120 mA (normal operation, rated voltage)
power consumption Approximately 3 W (normal operation, AC adapter used, 100 V side)
Operating temperature and humidity range temperature -10 ℃ ~ 50 ℃
Humidity 10% -90% RH (but no condensation)
Dustproof and waterproof performance * 4 IP grade: IP54 (excluding microphone part) Refer to the precautions regarding waterproofing
Size / weight Approximately 255 mm (H) x 76 mm (W) x 33 mm (D) ・ Approximately 400 g (including batteries)
accessories Storage case x 1, Windscreen WS-10 x 1, Windscreen fall-prevention rubber x 1, Strap x 1, AA batteries (alkaline) x 4, SD card 512 MB
