Rion รหัส UV-15 เครื่องวัดการสั่นสะเทือน,Charge Amplifier,Vibration Signal Conditioner,Meter Unit

• Wide range of accelerometers supported (CCLD, TEDS, and charge) – sensitivity range 0.1 – 99.9 mV/ms-2 and 0.1 – 99.9 pC/ms-2

• UV-15 can be deployed close to the sensor and analogue or digital (USB or LAN using UV-22) can be relayed back to data acquisition system

• UV-15 can alternatively be used to collect data from a charge accelerometer at the end of a long extension cable (EC-02 Series) via pre-amp input using a Rion VP-26A pre-amp (option)

• On-board integrators – measures acceleration, velocity and displacement

• Selectable display of rms, equivalent peak or equivalent peak-to-peak

• 1Hz – 15 kHz frequency response ± 5% (0.5 Hz – 30 kHz 10%) for acceleration

• Analogue a.c. and d.c. outputs

• TEDS, CCLD inputs and separate a.c. and d.c. outputs via industry standard BNC sockets on rear panel

• Output available via LAN or USB when used with UV-22

• Numeric display with 1 second refresh rate

• Bar graph display with 100msec refresh rate

• Ten hi-pass and ten lo-pass filter points (can be selected independently or switched out)

• Additional hi and lo pass filter frequencies available when used with UV-22

• Power supply 9 – 15V d.c. (12V nominal) via suitable adapter or Battery Unit BP-17

• Master/slave function enables settings on multiple instruments to be manually adjusted simultaneously when connected to UV-22
