ShowaSokki รุ่น 1332-B เครื่องวัดความสั่นสะเทือนแบบดิจิตอล,Portable digital display vibration meter,meas.range:0.1～199.9m/s2

1332B

1332B-01H

1332B-01L

1332B-00F

Acceleration measurement range

Hi
(peak)

0.1 to
199.9 m/ ^s2

1 to
1999m/ ^s2

0.01 to
19.99 m/ ^s2

0.1 to
199.9 m/ ^s2

Low
(peak)

0.01 to
19.99 m/ ^s2

0.1 to
199.9 m/ ^s2

0.001 to
1.999 m/ ^s2

0.01 to
19.99 m/ ^s2

Velocity measurement range

Hi
(RMS)

0.1 to
199.9mm/s

1 to
1999mm/s

0.01 to
19.99mm/s

0.1 to
199.9mm/s

Low
(RMS)

0.01 to
19.99mm/s

0.1 to
199.9mm/s

0.001 to 0.999mm/s

0.01 to
19.99mm/s

Displacement measurement range

Hi
(PP)

0.01 to
19.99mm

0.01 to
19.99mm

1 to
1999 μm

0.01 to
19.99mm

Low
(PP)

0.001 to
1.999mm

0.001 to
1.999mm

0.1 to
199.9 μm

0.001 to
1.999mm

Frequency range

acceleration

5 to 5,000Hz (±1dB)
5 to 10,000Hz (±3dB)

5 to 5,000Hz
(±1dB)

5 to
1,000Hz
(±3dB)

speed

10 to 1,000 Hz (conforms to JIS B 0907, the standard
for )

10 to
1,000Hz
(±3dB)

displacement

10 to 1,000Hz (±1dB)

10 to
1,000Hz
(±3dB)

Measurement accuracy
80Hz
20±5℃
1/2FS

acceleration

±3%±1 digit

speed

±5%±1 digit

displacement

±5%±1 digit

temperature range

Detector: -20°C to +110°C Amplifier: -10°C to +50°C

AC output

±2V (full scale)

power supply

Alkaline battery AA type (LR6) / 2 pcs. 30 hours or more

Dimensional mass (body)

75 (W) x 130 (H) x 24 (D) mm Approx. 230g

Detector

MODEL-2304A

MODEL-2369

MODEL-2302B
