Imada รุ่น PS-30K เกจวัดแรงดึงแรงดันแบบหน้าปัดเข็มอ่านค่าละเอียดสูงหน่วยกิโลกรัม , High accuracy push/pull mechanical force gauge,kilogram-force(Kgf)unit ,capacity: 30 kgf ,resolution: 300 gf

The PS/PSS series dynamometers are high quality analog measuring instruments. This instrument represents the standard model in the Imada mechanical dynamometer line. Robust and reliable over time, with a reading dial expressed in Kilograms, Pounds or Newtons. Precise and easy to use, it does not require maintenance.

Analog dynamometers for direct tensile and compression tests. Reliable over time thanks to the first choice construction materials: the only ones to be made with a die-cast and painted aluminum casing. They have a mechanical operation without batteries and are intrinsically safe in hostile environments. The robust construction of the PS/PSS series dynamometers makes them ideal for industrial environments and allows the measurement characteristics to be maintained unchanged over time. The ergonomic design is studied for handheld use but it is possible to mount the instrument on tripods or translators.

Models are available in various capacities and with various scales to meet different measurement needs (the scales are in Newton, Kg, lb). The PS/PSS models have a precision of ±0.1% FS and offer continuous reading of the measured values or peak storage via a side button that blocks the indicator on the maximum value reached. The circular ring of the dial allows you to adjust the zeroing of the indicator needle to compensate for the weight of any accessories, grips or to compensate for small variations in the load due to the position of use. The hand locking system allows the reading of transient phenomena or the peak load.

• Stroke : 10 mm
• Scaling : 100 lignes (120 lines for 3K, 30K, 30N, 300N)
• Accuracy :± 0,1% of full scale
• PEAK Hold function
• Shaft thread : M6
• Weight : 600 g
• Dimensions 67 x 48 x H 232
• Reading in kgf or Newton
• Easy handling with less risk of malfunctions or glitches caused by external circumstances such as noise or static electricity due to the rugged mechanical construction
• Ideal for pricision measurements with the highest accuracy
• Measures both compression and tension force
• Captures peak value easily using switchable peak hold function
• Assists accurate measurement with tare ring to adjust zero
