Tohnichi รุ่นCTB50N2X12D-G-SH12DX19 ประแจวัดแรงบิดแบบดิจิตอลชนิดเปลี่ยนหัวได้,Digital retightening torque wrench,capacity:10～50Nm.

Accuracy ±1%

MODEL

CTB50N2X12D-G

TORQUE RANGE
[N • m]

MIN.～MAX.

10～50

1 DIGIT

0.05

TORQUE RANGE
[kgf • cm]

MIN.～MAX.

100～500

1 DIGIT

0.5

TORQUE RANGE
[kgf • m]

MIN.～MAX.

1～5

1 DIGIT

0.005

TORQUE RANGE
[lbf • in]

MIN.～MAX.

100～440

1 DIGIT

0.5

TORQUE RANGE
[lbf • ft]

MIN.～MAX.

7.5～36

1 DIGIT

0.05

MAX. HAND FORCE [N]

10～50

DIMENSION
[mm]

EFFECTIVE LENGTH

L

0.05

OVERALL LENGTH

L'

282

HEAD

d3

12

WEIGHT [kg]

0.58

INTERCHANGEABLE HEAD

（SH,RH,QH,RQH,DH,HH）
12D

DISPLAY

7 segments LED 4 lines 10 mm

14 segments LCD 6 lines 7 mm

7 segments LED 4 lines 3 mm

Battery Life Indicator（ 4 steppes )

Judgment LED RED / BLUE

MEMORY

999（M-2 mode: 99 data)

COMMUNICATION FUNCTIONS

RS232C（ 2400～19200 bps )

Serial output corresponding to a USB connector

POWER SUPPLY

Ni-MH rechargeable battery

CONTINUOUS USE

Approx. 20 hrs with fully charged（ 8 hrs by 1 hour recharging )

RECHARGING TIME

Approx. 3.5 hrs

OPERATION TEMPERATURE[℃]

0～40 no condensation

BASIC FUNCTION

Peak Hold

Peak Data Memory with date and time

Auto Memory & Resetting

Tightening Completion Buzzer

Judgment of Measured Data

Auto Zero setting

Auto power off（ 3 min )

Clock
