Draeger รหัสสินค้า CH23201 หลอดวัดความเข้มข้นของก๊าซ , Gas detector tubes Carbon Disulfide 30/a , meas.range: 32~3,200 ppm , quantity: 10pcs/Box

Draeger รหัสสินค้า CH23201 หลอดวัดความเข้มข้นของก๊าซ , Gas detector tubes Carbon Disulfide 30/a , meas.range: 32~3,200 ppm , quantity: 10pcs/Box
Draeger รหัสสินค้า CH23201 หลอดวัดความเข้มข้นของก๊าซ , Gas detector tubes Carbon Disulfide 30/a , meas.range: 32~3,200 ppm , quantity: 10pcs/BoxDraeger รหัสสินค้า CH23201 หลอดวัดความเข้มข้นของก๊าซ , Gas detector tubes Carbon Disulfide 30/a , meas.range: 32~3,200 ppm , quantity: 10pcs/BoxDraeger รหัสสินค้า CH23201 หลอดวัดความเข้มข้นของก๊าซ , Gas detector tubes Carbon Disulfide 30/a , meas.range: 32~3,200 ppm , quantity: 10pcs/Box
รหัสสินค้า SKU-21349
หมวดหมู่ หลอดวัดความเข้มข้นของก๊าซ(Gas detector tube),Draeger
ราคาปกติ 6,000.00 บาท
ลดเหลือ 0.00 บาท
สถานะสินค้า Pre-Order
ลงสินค้า 30 มี.ค. 2567
อัพเดทล่าสุด 30 มี.ค. 2567
คงเหลือ 1 ชิ้น
จำนวน
ชิ้น
หยิบลงตะกร้า
หนังสือรับรองบริษัท
บุ๊คแบ๊งค์
คุ้มครองโดย LnwPay


› Click here to download the Technical Specification for this product.›

Carbon Disulfide Detection Tubes 30/a (32 - 3200 ppm)

For short-term measurements more than 160 Draeger-Tubes are available to measure the spot concentrations of specific gases. Measurement usually takes between 4 seconds and 15 minutes. The tubes are used either manually with the Draeger-Tube Accuro Pump or automatically with the Draeger X-act 5000.

A wide range of different gases and vapours can be detected and measured, such as:

  • Determining and measuring concentration peaks
  • Measuring personal exposure in the inhalation area
  • Detecting leaks in pipelines, gas installations etc.
  • Air analysis in sewers, shafts and confined spaces

  • Hard-to-reach places can be accessed and measured using various compatible accessories
  • Excellent for on-the-spot measurements
  • 10 seconds to 15 minutes is the time frame for readings and is totally dependent on the tube type
  • Suitable applications include pre-entry checks, confined space entry, variations in concentration levels and also contamination of breathing areas are amongst a number of potential of applications

Carbon Disulfide Detection Tubes 30/a (32 - 3200 ppm)

Standard Measuring Range:

0.1 to 10 mg/L

Number of Strokes (n):

6

Time for Measurement:

approx. 1 min.

Standard Deviation:

±15 to 20 %

Color Change:

pale blue ?> brown

Temperature:

0 to 40° C

Absolute Humidity:

< 30 mg H2O / L

Reaction Principle:

2 CS2 + 4 NHR2 + Cu2+ ?>
Cu(SCSNR2)2 + 2 NH2R2+

Cross Sensitivity:

Hydrogen sulfide is indicated, producing a pale green discoloration. It is impossible to measure carbon disulfide in the presence of hydrogen sulfide.
