รหัสสินค้า | SKU-14989 |
หมวดหมู่ | •เครื่องวัดความเข้มข้นของออกซิเจนในอากาศ(Oxygen concentration meter) |
ราคาปกติ | |
ลดเหลือ | 0.00 บาท |
สถานะสินค้า | Pre-Order |
ลงสินค้า | 30 เม.ย. 2566 |
อัพเดทล่าสุด | 19 พ.ค. 2568 |
คงเหลือ | 1 ชิ้น |
จำนวน | ชิ้น |
Peak value memory function
Displays the peak value from power ON to operation and elapsed time after recording the peak value. You can check the status of the site after work.
Peak hold function
After the operation, the peak value is always displayed on the screen. You can check the peak value without any operation during work.Peak value memory function
Displays the peak value from power ON to operation and elapsed time after recording the peak value. You can check the status of the site after work.
Peak hold function
After the operation, the peak value is always displayed on the screen. You can check the peak value without any operation during work.
Detection target gas | oxygen |
Gas sampling method | Diffusion type |
Detection principle | Membrane galvanic cell sensor |
Detection range (service range) |
0 to 25.0vol% (25.1 to 50.0vol%) |
Alarm setpoint | 1st stage: 19.5vol% 2nd stage: 18.0vol% |
Response time*1 | within 20 seconds |
Display method | LCD digital (manual backlight) |
Alarm system | Buzzer, flashing red lamp, liquid crystal display, vibration |
Attached function | Battery level display Peak hold function Peak value memory function Alarm functions other than gas alarm (sensor error, battery level, zero adjustment failure) |
Operating temperature and humidity range | -10°C to 40°C, 30 to 90% RH or less (no condensation) |
power supply | 1 AAA alkaline battery |
Continuous use time*2 | Approx. 5000 hours (when no alarm (gas concentration display is 20.3 vol% or more), at 20°C) |
External dimensions | W65×H64×D22mm (excluding protrusions) |
weight | about 75g |
Standard accessories |
|
