B.A.T. รุ่น DiGI-BELT XF-3000-Kit เครื่องวัดความตึงแบบกดที่สายพายพาน,Belt tension tester digital measurement

Model

3000

N

kgf

ozf

lbf

Resolution:

0.1

0.01

1

0.1

Capacity

500

50

1800

110

Accuracy:

± 0.3% F.S.

Selectable Units:

N, kgf, ozf, and lbf. (Depending on Range)

Overload Capacity:

150% of F.S. (LCD flashes beyond 110% of F.S.)

Measurement Method:

Peak, Track, Preset

Data Sampling Rate:

1,000 Hz

Display:

160*128 dot matrix LCD with Backlight

Display Update Rate:

10 times/second

Memory:

500 data

Set Point:

Programmable high and low limits in Preset Mode

Battery Indicator:

Display flashes battery icon when battery is low

Power:

3.6VDC 800mAH Ni-MH rechargeable batteries

Battery Life:

Approximately 16 hours continuous use per full charge

Charger / Adaptor:

Universal USB/BM charger, Input: 110 ~240VAC

Temperature Effects:

<0.054% per °F (0.03% FS per °C)

Outputs:

USB, RS-232; High & Low Limit NPN’s

Operating Temperature:

14 to 104°F (-10 to 40°C)

Storage Relative Humidity:

20 to 80%

Housing:

Aluminum

Storage Temperature:

-4 to 122°F (-20 to 50°C)

Oper. Relative Humidity:

5 to 95%

Dimensions:

5.5 x 2.8 x 1.4” (140 x 71 x 35.5 mm)

Product Weight:

0.9 lb (0.4 kg)

Package Weight:

2.25 lb (1 kg)

Certification:

CE

Included Accessories:

AC Adaptor/Charger, USB cable, calibration cert.,
6 attachments: hook, flat tip, conical tip, chisel tip,notched tip, extension shaft.
