- Sound measurements
- Environmental noise
- Occupational noise
- Building acoustic
- Ultrasound/infrasound
- High level/low level noise
- Machine vibration
- Tonality measurement
Specifications:
Standards
|
Class 1: IEC 61672-1:2002 (PTB approval 21.21/13.06)
|
Number of Profiles
|
3
|
Weighting Filters
|
A, B, C, Z, G
|
Time constants
|
Slow, Fast, Impulse
|
RMS Detector
|
Digital True RMS detector with Peak detection, resolution 0.1 dB
|
Microphone
|
GRAS 40AE, 50 mV/Pa, prepolarised 1/2” condenser microphone
|
Preamplifier
|
SV 17 IEPE type / 200V external polaristation compatible
|
Linear Operating Range
|
22 dBA RMS ÷ 140 dBA Peak (in accordance to IEC 61672)
|
Total Dynamic Measurement
|
Range12 dBA RMS ÷ 140 dBA Peak (typical from noise floor to the maximum level)
|
Internal Noise Level
|
less than 12 dBA RMS
|
Dynamic Range
|
>110 dB
|
Frequency Range
|
3.15 Hz ÷ 20 kHz with GRAS 40AE microphone
|
Meter Mode Results
|
SPL, Leq, SEL, Lden, LEPd, Overload time, Ltm3, Ltm5, LMax, LMin, LPeak Simultaneous measurement in three profiles with independent filters and detectors
|
Statistics
|
Ln (L1-L99), complete histogram in meter mode, averaging: linear of with detector (exponential) Ln (L1-L99) statistics in 1/1 or 1/3 octaves (if option is active)
|
Data Logger
|
logging of summary results with step from 10 s (auto-save function) logging of time history with step from 2 ms
|
Audio Recording (option)
|
Audio events recording during measurement, trigger or continuous mode, 12 / 24 / 48 kHz sampling rate, 16 or 24 bit, wav format
|
Wave Recording (option)
|
Time domain signal recording during measurement 12 / 24 / 48 kHz sampling rate, 16 or 24 bit, wav format
|
|
