| Model |
HRM-120E |
| display |
liquid crystal |
| Waterproof function (equivalent to PX5) |
waterproof |
| operation switch |
Membrane switch (with click) |
| Input connector |
ASP connector (thermocouple homogenous metal) |
| input |
Thermocouple input (type E) |
| number of inputs |
1point |
| signal source resistance |
1 kΩ or less |
| range of measurement |
0.1 resolution |
-104.9 to 204.9℃ |
| 0.01°C resolution |
-104.99 to 199.99°C (when using the temperature sensor dedicated to the HRM series)* |
| Measurement accuracy |
0.1°C resolution |
-104.9 to 204.9°C: ±0.1°C |
| 0.01°C resolution |
-104.99 to 199.99°C: ±0.10°C (when using the temperature sensor dedicated to the HRM series)* |
| Reference junction compensation accuracy |
±0.10°C (at 25°C ±10°C) |
| Temperature coefficient (only when exceeding 25°C ±10°C) |
Add the value obtained by multiplying the temperature Δt exceeding ±0.005×Δt°C by the coefficient to the display tolerance (= measurement accuracy + reference junction compensation accuracy). Example: 50°C, 0°C environment plus ±0.075°C |
| operating conditions |
Within 0 to 50°C, 0 to 80% RH (no condensation) |
| Storage conditions |
-20 to 50°C, within 0 to 85% RH (no condensation) |
| Usage time |
about 600 hours |
| battery |
Alkaline AA batteries (6 LR) x 4 |
| sampling period |
about 500ms |
| Linearization method |
Digital linearization method (compliant with JIS C 1602-2015) |
| External dimensions |
Approx. 82(W) x 166(H) x 36(D) mm (excluding protrusions) |
| mass |
About 350g (including batteries) |
| accessories |
Instruction manual, test report (main unit), warranty card, soft case, hand strap, alkaline batteries (6 LR) x 4 |
| Radio law (IC tag reading) |
Standard number: ARIB STD-T82 Model designation number: FC-200001 Standard name: Inductive read/write communication equipment (wireless card system, etc.) |
