Betten รุ่นNM-200เครื่องและเกจวัดแรงตึงสิ่งทอเส้นด้าย,Textile Tension Meter,Meas.head Width:70mm,Tension range:1～200g.

• The patented technology automatically resets the meter to zero , which improves the measurement accuracy and facilitates measurement.
• The tested material, the guide roller, and the screen are located on the same plane., the test data, the status of the guide roller and the tested material can be seen During the test.
• The screen display direction can be changed according to the customer's holding method, which is convenient for reading.
• g, c N can be selected as the unit for measuring value display.
• Record the maximum value, minimum value and average value during the measurement.
• Equipped with lead frame and guide roller movement structure, easy to capture the tested material
• The measuring head of the NTS is a ball bearing V-groove guide roller with a maximum speed of 900 m / min
• LIPO lithium-ion polymer battery (about 30 hours of continuous operation)

·       Specifications

o   Accuracy : (calibration material) ± 1% of full scale (FS), (other materials) ± 3% of full scale (FS)

o   Display update frequency 0.5 seconds

o   Optional unit              g, cN

o   Line speed NTS        900m / min

o   Stored value             Maximum, minimum, average

o   Display                    LCD

o   Case size                 225X45 X 30 mm

o   Power                      Li-ion rechargeable battery, continuous  working for about 30 hours

o   Operating temperature    10-45 ° C, 90% relative humidity or less

o   Shipment include            tension meter, instruction manual, certificate, charger, instrument box

o   Scope of application Tension measurement of yarn, chemical fiber, fine metal wire in textile, chemical fiber, wire and cable industry
